Has component placement cost time and money?

The challenge isn't just creating the schematic.

It's making sure every component, PLC, and accessory part is accurately represented inside the physical enclosure. Better predictions mean less rework and less back and forth clarification.

That's where SOLIDWORKS Electrical Panel Layouts can improve drawing accuracy compared to reality.

Every component in your electrical project can include a 2D footprint-a scaled representation of its physical appearance and dimensions.

This allows engineers to quickly generate accurate panel layouts directly from project data.

In this example:

• A PLC chassis is inserted into the panel layout
• Input and output modules are placed into their assigned rack positions
• Component labels are automatically maintained
• Physical placement matches the actual hardware configuration
• The layout remains fully linked to other component details in exported PDF's

Because the panel layout is built from real component data, engineers gain:

✅ More accurate documentation
✅ Faster panel design workflows
✅ Better space planning
✅ Improved installation readiness
✅ Greater confidence before manufacturing

The layout can also be viewed and scaled dynamically, fitting your drawing space while maintaining dimensional accuracy.

This becomes especially valuable for:

A well drawn schematic tells you how a system works. A realistic panel layout tells you how to build it.

Want to learn more SOLIDWORKS Electrical workflows and automation techniques?

Explore GSC's upcoming free webinars and technical training events:
