How do you transition a circuit from charging a capacitor to discharging it through a bulb -- without disconnecting a single wire?

In this video, Dr. Wargo introduces a powerful circuit component: the Double Pole, Double Throw (DPDT) switch. While standard switches simply open or close a single path, the DPDT switch allows you to fundamentally reroute current across two separate isolated circuits simultaneously.

We challenge you to think like an engineer: How would you wire this unique switch to achieve seamless, uninterrupted control? Watch as we break down the underlying circuit architecture, map out the internal connections, and demonstrate an elegant hardware solution that eliminates messy component swapping.
